AVERAGING TEMPERATURE SENSORS
Tasseron’s Averaging Temperature Sensors feature the patented quick coupling system for one-person installation. The temperature sensor elements are also marked inside the aluminum tubing, which allows strategic location for ideal temperature measurement.
These come in three standard flexible lengths of 8ft, 12ft, or 24ft, with an option for an 18 inch rigid version. Housing options include: Galvanized Steel Box, Mini, Flange of Safe Box (NEMA 4X) enclosures.
Tasseron’s Averaging Series are considered custom products and are made to order per desired specifications. The Averaging Series fall under non-standard warranty and return policies.
FLEXIBLE AVERAGING
High quality multipoint averaging temperature sensors with options for NEMA 4X / IP65 Euro or Galvanized Steel Box enclosures. Available measuring elements interface with most major control manufacturers. Accurate interchangeable thermistors ensure low drift and are double encapsulated to guarantee the highest reliability. Transmitters available with 4-20mA, 2-wire loop connection in 5 standard pre-set temperature ranges.
OVERVIEW
FEATURES
Options for NEMA 4X / IP65 Euro or Galvanized steel box enclosures
Multipoint sensor PVC wire with in 8ft, 12ft, or 24ft lengths
24’ with 9 points of measurement
12’ with 9 points of measurement
8’ with 4 points of measurement
NTC thermistors, RTD elements and 4-20mA transmitters available
Quick Connect wire terminals for tool free termination
Compatible with most major control systems
CE & RoHS compliant
5 Year Limited Warranty
Made in USA
AVERAGING euro
OVERVIEW
High quality duct averaging temperature sensor with a NEMA 4X / IP65 enclosure. Sensing tube is 3/16" (4.8mm) diameter flexible copper tubing, and 18" 316L rigid stainless steel.
Available measuring elements interface with most major control manufacturers. Accurate interchangeable thermistors ensure low drift and are double encapsulated to guarantee the highest reliability. The quick connect terminals eliminate wire nuts for a faster, more reliable installations and reduces installation costs.
FEATURES
NEMA 4X / IP65 enclosure
Copper tube lengths: 8’, 12’, 24’ or Rigid Probe (Stainless Steel) Length of 18”
Quick Connect wire terminals eliminate wire nuts
NTC thermistor, RTD elements and 4-20mA transmitter available
Compatible with most major control systems
1/2” NPT conduit adapter included in Safe Box & Euro option
CE & RoHS compliant
5 Year Limited Warranty
Made in USA
AVERAGING MINI
OVERVIEW
High quality duct averaging temperature sensor with injection-molded flange. Patent Pending water tight Quick Coupling allows for disconnection of the sensing tube to the enclosure, for fast installation. Sensing tube is 3/16" (4.8mm) diameter flexible aluminum tubing, and 18" 316L rigid stainless steel.
Available measuring elements interface with all major control manufacturers. Accurate interchangeable thermistors ensure low drift and are double encapsulated to guarantee the highest reliability. The Quick Connect wire terminals eliminate wire nuts for a faster, more reliable installations and reduces installation costs.
FEATURES
Durable IP54 injection-molded enclosure with Quick Snap Cover
Lengths: 8', 12’, 24’ and 18”
24’ with 9 points of measurement
12’ with 4 points of measurement
8' with 4 points of measurement
18” with 4 points of measurement
Patent Pending Quick Coupling from enclosure to sensing tube
Quick Connect wire terminals eliminates wire nuts
NTC thermistors, RTD elements and transmitters available
1/2” NPT conduit adapter indluded
Compatible with most control systems
CE & RoHS compliant
5 Year Limited Warranty
Made in USA
AVERAGING G-BOX
OVERVIEW
High quality duct averaging temperature sensor with an IP40 galvanized steel enclosure. The Patented water tight Quick Coupling allows for disconnection of the sensing tube to the enclosure, for fast installation. Sensing tube is 3/16" (4.8mm) diameter flexible aluminum tubing, and 18" 316L rigid stainless steel.
Available measuring elements interface with most major control manufacturers. Accurate interchangeable thermistors ensure low drift and are double encapsulated to guarantee the highest reliability. The Patent Pending Quick Connect system eliminates wire nuts for a faster, more reliable installations and reduces installation costs.
FEATURES
Galvanized IP40 enclosure with Quick Attach Cover
Lengths: 8', 12’, 24’ and 18”
24’ with 9 points of measurement
12’ with 4 points of measurement
8' with 4 points of measurement
18” with 4 points of measurement
Patent Pending Quick Coupling from enclosure to sensing tube
Quick Connect wire terminals eliminates wire nuts
NTC thermistors, RTD elements and transmitters available
Compatible with most control systems
CE & RoHS compliant
5 Year Limited Warranty
Assembled in USA
AVERAGING FLANGE
OVERVIEW
High quality duct averaging temperature sensor with an IP54 injection-molded enclosure. The Patented water tight Quick Coupling allows for disconnection of the sensing tube to the enclosure, for fast installation. Sensing tube is 3/16" (4.8mm) diameter flexible aluminum tubing, and 18" 316L rigid stainless steel.
Available measuring elements interface with most major control manufacturers. Accurate interchangeable thermistors ensure low drift and are double encapsulated to guarantee the highest reliability. The quick connect terminals eliminate wire nuts for a faster, more reliable installations and reduces installation costs.
FEATURES
Durable injection-molded plastic mounting flange
Lengths: 8', 12’, 24’ and 18”
24’ with 9 points of measurement
12’ with 4 points of measurement
8' with 4 points of measurement
18” with 4 points of measurement
Patent Pending Quick Coupling from enclosure to sensing tube
Quick Connect wire terminals eliminates wire nuts
NTC thermistor and RTD elements available
Compatible with most control systems
CE & RoHS compliant
5 Year Limited Warranty
Assembled in USA
AVERAGING SAFE
OVERVIEW
High quality Duct Averaging Temperature Sensor with a NEMA 4X injection molded enclosure. Patented water tight Quick Coupling allows for disconnection of the sensing tube to the enclosure, for fast installation. Options include variable length flexible aluminum tubing or rigid 316 stainless steel tube.
Available measuring elements interface with all major control manufacturers. Accurate interchangeable thermistors ensure low drift and are double encapsulated to guarantee the maximum reliability. The Quick Connect wire terminals eliminate wire nuts for a faster, more reliable installation and reduces installation costs.
FEATURES
Durable injection-molded NEMA 4X watertight enclosure
Lengths: 8’, 12’, 24’ coiled and 18” rigid
24’ with 9 points of measurement
12’ with 4 points of measurement
8” with 4 points of measurement
18” with 4 points of measurement
Patented Quick Coupling from enclosure to sensing tube
Quick Connect wire terminals eliminates wire nuts
Built in 1/2” NPT conduit adapter
1/2” NPT conduit adapter included
NTC thermistors, RTD elements and transmitters available
Compatible with most control systems
CE & RoHS compliant
5 year limited warranty
Assembled in the USA
